Virtual Tours: Seismic & Vibration Installation Details
Each tour is a 3D model of an equipment room with our isolation and seismic restraint products installed. Walk around, zoom in on any connection and click the product markers to see what is used where. Tours open in a new tab.
Boiler Room
A boiler on rubber pads and snubbers, its pumps on seismic isolators and its flues hung and braced.
Open 3D tour Boiler Room (opens in a new tab)
Generator Room
A generator set on seismic spring isolators, its exhaust carried on spring hangers and braced with cables.
Open 3D tour Generator Room (opens in a new tab)
Cooling Tower
A rooftop cooling tower on heavy-duty seismic spring isolators.
Open 3D tour Cooling Tower (opens in a new tab)
Pump Station
A pump set and its header on seismic spring isolators, with the risers hung and braced.
Open 3D tour Pump Station (opens in a new tab)
Electrical Panels
Rows of floor-standing electrical panels braced back to the structure with cables.
Open 3D tour Electrical Panels (opens in a new tab)
Condensing Unit
A rooftop condensing unit on rubber pads, restrained with seismic cable bracing.
Open 3D tour Condensing Unit (opens in a new tab)
